High performance 300cm (10ft) C/Ku-Band polar mount prime focus mesh satellite dish. The large size and tight beamwidth of this dish ensures you will receive 100% of North American TV broadcasts and 100% of Central and South American TV broadcasts. You will get everything!!! It can be used as a stationary dish (includes lock down bar) or fully motorized with an actuator (not included) to track multiple satellites. The aesthetic appeal of this mesh dish makes it perfect for urban and rural areas where reliable C-Band reception is required. This dish is recommended for commercial use, for hobbyists, or for residential users in Northern Canada, Alaska, Hawaii, Caribbean, Central/South America or other areas outside of the main North American satellite footprints and require additional signal gain.
Note: This is our 7th generation (2018) model with heavy-duty mount, superior steel construction, larger arm, and thicker gauge steel for minimal slop. Field proven and reliable or your money back!
Similar Products In Stock HERE
Note: Requires 4.5″ O.D. mounting pole which is sold separately.
Note: This antenna is intended for residential use.
FEATURES
Precise parabolic shape
8-panel construction for more precise geometry
Sturdy construction and light weight
Prime Focus quad feed support
Small hole(< 1.5mm) mesh ensures Ku-Band signal reception is just as reliable as C-Band signal reception
1.0mm mesh thickness for strength
Package includes:
- 8 Mesh Panels
- Mounting Frame
- 4 LNBF struts
- Declination bracket
- Mounting nuts and bolts
- Feed Cover
Note: Actuator motor is SOLD SEPARATELY. See our other listings
TECHNICAL
Specification Value
Antenna Construction Material: Aluminum Mesh
Hole size 0.06″ (1.5mm)
Panels 8
Rib size 1″ (2.54cm) sq.
Feed Support Rods 4
Strut Length 59″ (149.9cm)
Strut Mount 8.5″ (21.6cm) from rim on panel face
Aperture Diameter (inner) 119″ (302.3cm)
Focal Length 46.0″ (116.8cm)
F/D Ratio 0.385
Finish Polyester Powder Coating
Color Black / Glossy Black
Weight 125 lbs
Performance
C-Band Gain(@4.2GHz) 40.3dBi (Typ)
Ku_band Gain(@12.2GHz) 48.3dBi (Typ)
C-Band Mainlobe Beamwidth 1.75°
Ku-Band Mainlobe Beamwidth 0.55°
Mounting
Mounting Type Polar Mount
Polar Frame Size 34″ (86.4cm) diameter
Elevation Angle Range 0° to 90°
Azimuth Range 0° to 360°
Declination Adjustment 0° to 10°
Recommended Pole Dimension 4.5″(114.3mm)
Strut Mount 8.5 inches (21.6cm) from rim on panel face
Environment
Operational Winds 90km/h
Survival Winds 150km/h
Ambient Temperature -50°C to +60°C
Relative Humidity 0~100%
Shipping Details
Box 1 (Mount) 37″x37″x7″ Rectangular (65 lbs)
Box 2 (Panels) 62″x48″x11″ Pie (60 lbs)
